OEM Phenolic Wear Ring High Load Resin Brown Guiding Ring Fabric Reinforced

Basic Information

Place of Origin:	China
Brand Name:	Joyreap
Certification:	ISO,IATF16949
Model Number:	PFC-60

Minimum Order Quantity:	20pcs
Packaging Details:	Wrapped the Wear Ring with plastic paper and put them into export cartons or wooden case
Delivery Time:	25-30 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	50000/month

Get Best Price Contact Now

Detail Information

Description:	Guiding Ring	Material:	Composite Fiber Fabric
Advantages:	High Load,heat Resistance	Color:	Brown
OEM:	YES
Highlight:	OEM Phenolic Wear Ring , Phenolic Wear Ring High Load , Brown Guiding Ring

Product Description

Fabric Reinforced Guide Rings Phenolic Resin Brown High Strength

PFC-60 high strength Fabric Reinforced Phenolic Resin brown Guide Rings is based upon new type of phenolic resin, reinforced with specialty synthetic fiber and processed under certain temperature and pressure. PFC-60 has good mechanical strength and flexibility, superior wear resistance and low friction, thus allows it can adapt all types of service conditions.

Material

phenolic resin+specialty synthetic fiber

Advantages

High strength
lexibility, superior wear resistance
low friction

Application

High Pressure Oil Cylinder Guide Rings
Engineering Machinery Guide Rings, Bushings, Shaft Sleeves
Mining and Coal Machinery EquipmentSupport Rings
Hydraulic Machinery, Forging Machinery Tool Guide Bushings

Technical Data

Specification	Color	Density 3(g/c㎡)	Tensile strength	Compressive strength		Hardness	Coefficient of friction		Temperature
									(℃)

				Parallel to the laminated plane	Vertical to the		Dry	Oil lubrication
					laminated plane
PFC-60	Brown	1.2-1.4	≥45 (MPa)	≥140	≥340	90	0.15-0.3	0.05-0.12	-40 ～ +130
