Name: Metal Plain Bearing PTFE Coated Composite DP4 Bushing
Brand: Jiaxing Joyreap Precision Machinery Co.,Ltd
SKU: ZR-015
Availability: InStock

Detail Information

Description:	Lead Free Bushing	Material:	Steel+bronze+PTFE
Code:	DP4	Application:	Automotive Industry
Name:	Metal Plain Bearing	Keywords:	DP4 Bushing
Highlight:	Metal Plain Bearing , Metal Plain Bearing PTFE , DP4 Bushing

Product Description

Bushing PTFE Coated Metal Polymer Composite Plain Bearing DP4 Bushes

ZR-015 self-lubricating bearing is the lead free type of ZR-010 bushing. This type of DU bushing has the same structure of ZR-010 sliding bearing. It's also called DU bushing, PTFE based self lubricating bushing, sliding bearing,plain steel bushing,LFB lead free bushes, SF-1 plain dry bearing and lead free oilless bearing.

Material Structure

Lead Free PTFE Lined Bearings Self Lubricating 0

1.PTFE mixture

2.Porous bronze

3.low-carbon steel backing

4.Tin-plating or copper plating

Characteristics

This type DU bushing has all the properties of PVB010 self lubricating bearing
Without lead which makes the bushing lubricating condition more cleaner.
Without lead which makes the bushing accord with environmental protection request

Application

ZR-015 lead free plain sliding bearing is widely used in lifting equipment, Hydraulics and valves, pneumatic equipment, medical equipment, textile machinery, agricultural equipment, construction equipment, meterial handing equipment, packaging equipment, automotive field, scientific equipment, drying ovens, office equipment, etc.

Technical Data

Specific load capacity (static)	≤ 250 [ N/mm ]
Specific load capacity (dynamic)	≤ 140 N/mm at low speeds
Specific load capacity (Rotating oscillating)	≤60N/m
Friction value	0.03 to 0.25
Temperature	-200 to +280 [ °C ]
Max. dry running Pv (Short-term operation)	3.6N/mm/s
Max. dry running Pv (Continuous operation)	1.8N/mm/s
Max. speed (dry running)	2m/s
Max. speed (Hydrodynamic operation)	＞2m/s

Tolerance Details

Housing ØH7
Bushing inner-Ø after mountingH9
Shaft tolerancef7 to h8

Mouting Suggestion

Housing: Mounting bevel min. 1.5 mm x 15-45°
Shaft Material:Steel, hardened or untempered, surface roughness ≤ Rz 2-3 Shaft: Mounting bevel 5 mm x 15°, edges rounded
The application of an adequate force fitting mandrel is advisable. Grease lubrication of the outer surface may be necessary when mounting.

Tag:

Place of Origin:	China
Brand Name:	Joyreap
Certification:	ISO,IATF16949
Model Number:	ZR-015

Packaging Details:	Cartons+Wooden Pallets
Delivery Time:	30 days
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	5,000,000PCS/Month
